Steel Structure Welding

The welding quality of steel structure determines its installation quality, no matter what the welding quality of steel structure is, some defects can not be avoided. Next, XinGuangZheng steel structure editor to take you to understand what are the common quality defects of steel structure welding?

(1) cracks:

Cracks are divided into hot cracks and cold cracks. The main causes of hot cracks are poor crack resistance of raw materials, poor quality of welding materials and improper selection of welding process parameters, while cold cracks are mainly caused by unreasonable welding structure design, incorrect welding layout, no preheating before welding and rapid cooling after welding.

Treatment: drill a crack stop hole at both ends of the crack, or remove the welded metal at the crack for repair welding.

(2) inclusion of slag:

It is usually caused by the poor quality of welding materials, the small welding current, the fast welding speed and the inability to remove slag in the process of multi-layer welding.

Treatment method: remove the weld metal in the slag inclusion, and then repair welding.

(3) non-melting:

The main reasons are that the welding current is too small, the welding speed is too fast, the groove gap is too small, and the operation process is not good.

Treatment method: remove the welding metal from the unfused area, and then weld it.

(4) Welding tumor:

It is caused by incorrect selection of welding process parameters, poor operation technology, improper placement of weldments and so on.

Treatment: use manual or mechanical methods such as shovels, files and grinders to remove excess metal.
